OKM Evolution NTX

€4.600,00 excl. IVA
€5.336,00 iva del 16%*
    • Principiante: Perfecto detector de nivel de entrada en la tecnología de escaneo de tierra 3D combinado con una bobina VLF para encontrar tesoros
    • Profundidad: Los clientes encontraron tesoros de hasta 5-8 metros de profundidad - ver nuestras referencias
    • Aplicaciones: caza del tesoro, prospección de oro natural, detección de cavidades
    • Modos de detección: Ground Scan, Live Sound
    • Objetos detectables: cofres del tesoro, cavidades, túneles
    • 24
    • 23
    • 22
    • 21
    • 20
    • 19
    • 18
    • 17
    • 16
    • 15
    • 14
    • 13
    • 12
    • 11
    • 10
    • 9
    • 8
    • 7
    • 6
    • 5
    • 4
    • 3
    • 2
    • 1

    Introduction of metal detector OKM Evolution NTX:

    YouTube Video

    How to use the metal detector OKM Evolution NTX:

    YouTube Video
    3D Visualization
    3D Visualization
    3D Ground Scan
    3D Ground Scan
    Color display / Touchscreen
    Color display / Touchscreen
    GST / EMSR
    GST / EMSR
    Height adjustment
    Height adjustment
    Inductive search coil
    Inductive search coil
    LED lighting
    LED lighting
    Live Sound
    Live Sound
    Multilingual operation
    Multilingual operation
    Rechargeable high-capacity battery
    Rechargeable high-capacity battery
    Speaker
    Speaker
    Wireless technology
    Wireless technology

    3D Metal detector for Treasure Hunters and Gold Seekers

    The metal detector and 3D ground scanner Evolution NTX can be used by treasure hunters, gold seekers, metal detectorists and archaeologists who are looking for buried objects, hidden artifacts or other lost items like:

    • Lost valuables (rings, coins, jewelries, wedding bands)
    • Buried treasures and artifacts
    • Ancient boxes, chests, chambers and sepulchers

    Unlike other metal detectors, the Evolution NTX can process graphical 3D images of underground treasure hoards and detected anomalies. Thus, you can determine size and depth of potential finds before digging. The deep penetration capability is just another advantage of our 3D ground scanner. Many great treasure finds prove the potential of our metal detecting technology made in Germany.

    Treasure find in Algeria with OKM Evolution
    January 23, 2014
    Tesoro encontrar en Argelia con el detector OKM Evolution

    Un buscador de tesoro argelino logró detectar un sable antiguo de 200 años.

    Leer más



    3D Metal Detector for Treasure Hunters and Gold Seekers

    The successor of EvolutionEvolution NTX, is more compact and comes with improved features like rechargeable internal batteries, easier usability and more powerful sensor and coil technology.



    Improved Usability

    Based on our experiences as well as suggestions of many OKM users the new model has been improved and optimized in various aspects:

    • Long-lasting and rechargeable batteries
    • Color touchscreen with higher resolution
    • Integration of Bluetooth headphones
    • More compact and robust design
    • Improved sensor and coil technology

    Full color display with touchscreen and multilingual user interface allow an easier usability and setup of the metal detector Evolution NTX. The brightness of the screen can be adjusted individually.



    VLF Metal Detector

    The combination of our sensor technology with a VLF search coil allows to detect not only near-surface metals, but also deeply buried artifacts and treasure objects.

    Evolution NTX with telescopic search coil: The length of the metal detector Evolution NTX can be adjusted to the individual body height of its user.



    Ground Scan and Metal Detection

    The 3D ground scanner Evolution NTX supports two operating modes to research the underground soils for hidden objects and structures. The length of the detector can be adjusted individually according to your own body height. Thus you can make this metal detector your metal detector.

    Starting at the main menu you simply select one of the operating modes:

    • Live Sound
      This operating mode activates the VLF metal detector to find shallow metal objects like coins, rings and other jewelry. Next to an acoustical output you can also see a simple graphical indication of the signals.
    • 3D Scan
      This operating mode is used to conduct graphical 3D ground scans. All scan data is stored into the device’s memory. Those information can be transferred to the Visualizer 3D Software to generate graphical 3D images of underground objects and structures.



    3D images via Visualizer 3D Software

    The metal detector and 3D ground scanner Evolution NTX can be used by treasure hunters, gold seekers, metal detectorists and archaeologists.

    With the 3D scan function and the software Visualizer 3D you can create a 3D graphic of the underground and find buried coins, rings, jewellery and similar treasure objects and artefacts. Especially metallic objects can be detected successfully. Buried objects are indicated by different colors in a graphical 3D representation.

    Archaeology
    Archaeology
    Cavity Detection
    Cavity Detection
    Explosive Ordnance Disposal Services
    Explosive Ordnance Disposal Services
    Militaria Detection
    Militaria Detection
    Natural Gold Prospection
    Natural Gold Prospection
    Treasure Hunting
    Treasure Hunting
    OKM Search Services
    OKM Search Services
    1x Control unit
    1x 3D Software ("Visualizer 3D")
    1x Waterproof and shock resistant Pelican case
    1x Bluetooth headphones
    1x USB Bluetooth dongle
    1x Charger for control unit
    1x Travel adapter
    1x User’s manual

    Control unit

    • Dimensions (H x W x D): 540–810 x 150 x 280 mm
    • Weight: approx. 1.5 kg
    • Input voltage (max.): 19 V DC, 3.16 A, 60 W
    • Processor / Main CPU: Cortex M3, 32 MHz
    • Processor / Slave CPU: Cortex M0, 24 MHz
    • Display: 3.5” Resistive touch, 480 x 320 Pixel
    • Display CPU: Cortex M3, 32 MHz, 128 KB RAM
    • Data memory: 4 GB
    • Sample rate: 1024 values / second
    • Measurement resolution: 16 bit
    • Operating temperature: –10°C – 60°C
    • Storage temperature: –20°C – 70°C
    • Audio: Internal speaker / Bluetooth
    • Waterproof: No
    • Technology: GST / EMSR
    • Sensor technology / Coil technology: SCMI-15-D / VLF
    • Air humidity: 5% – 75%

    Data transmission

    • Technology: Bluetooth
    • Frequency: 2.4 – 2.4835 GHz
    • Maximum Transfer Rate: 1 Mbps
    • Receiving Sensitivity: –85 dBm
    • Maximum Range: approx. 10 m

    Computer minimum requirements

    • CD-ROM drive: minimum 4x
    • Interface (Data transmission): USB
    • Free disk space: minimum 50 MB
    • Working memory (RAM): minimum 256 MB
    • Graphic card: minimum 128 MB, OpenGL-compatible
    • Processor: minimum 1.2 GHz
    • Operating system: Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10

    The technical data are average values. Minor deviations are possible during operation.
